🟢authorized PARTNER

SKU:PEEK-300

CreatBot PEEK-300 Industrial Grade FDM 3D Printer CPK-300

CreatBot PEEK-300 Industrial Grade FDM 3D Printer CPK-300

Regular price $13,999.00 USD
Regular price Sale price $13,999.00 USD
Sale Sold out

In stock

Includes Warranty

30-Day Returns

Unlimited Free Support


PEEK-300: The Pinnacle of Ultra High-Performance 3D Printing

The PEEK-300 is engineered for demanding industrial and medical applications, offering ultra-high-temperature capabilities and revolutionary features such as the Direct Annealing System (DAS). With industry-leading thermal systems and exceptional material compatibility, the PEEK-300 sets a new benchmark for 3D printing high-performance polymers.



  • Ultra-High Temp Hotend and Bed:
    • Hotend max: 480°C (dual extruder).
    • Heatbed max: 200°C.
  • Advanced Thermal System:
    • Hot chamber max: 120°C.
    • Triple heat isolation and liquid cooling ensure thermal stability.
  • Direct Annealing System (DAS):
    • Anneals parts during the printing process, eliminating the need for post-processing.
    • Adjustable temperature range: 0-200°C for customizable strength and toughness.
  • Large Build Volume: 300 x 300 x 400 mm, ideal for big models and complex designs.
  • Innovative Cooling System:
    • Combines liquid cooling with air pump technology for optimal temperature control.

Revolutionary Technology: Direct Annealing System (DAS)

The PEEK-300’s patented DAS technology is a game-changer in 3D printing:

  • Instantaneous: Annealing is completed during the printing process, eliminating secondary oven treatments.
  • Complete Filament Annealing: Targets each filament strand during extrusion for maximum crystallization and dimensional stability.
  • Controllable: Offers precise temperature adjustment to meet varying material and application requirements.

Material Compatibility

The PEEK-300 supports an extensive range of materials for diverse applications:

  • Engineering Plastics: PLA, PC, ABS, PA6, PETG, TPU, and more.
  • High-Temperature Materials: PPSU, PEI (ULTEM), PA12, and PPS.
  • Ultra-Performance Materials: Medical-grade PEEK, PEEK-CF (carbon fiber), PEEK-GF (glass fiber), and PEKK.

Additional Highlights

  • Smart Auto-Rising Dual Extruders: Water-cooled and capable of 480°C for unparalleled material versatility.
  • Hotbed Performance: Maintains a stable 200°C to ensure warp-free large-scale prints.
  • Hot Chamber: Keeps internal temperatures up to 120°C, preventing cracking in high-performance materials.

Custom Solutions and Support

  • Tailored Printing Services: We provide material recommendations and design suggestions for your specific applications, with complimentary sample printing available.
  • Comprehensive Support: Enjoy online and local technical support, on-site service, and training to maximize the value of your PEEK-300.

Experience the Future of High-Performance 3D Printing

Transform your manufacturing capabilities with the PEEK-300. Whether you’re producing medical-grade components, aerospace parts, or high-performance industrial tools, the PEEK-300 ensures unmatched precision, strength, and reliability.

Specs

Category Specification
Printing
Build Volume Single Extrusion: 300 x 300 x 400 mm
Dual Extrusion: 240 x 300 x 400 mm
Filament Diameter 1.75 mm
Number of Nozzles Dual Extruder
Nozzle Diameter 0.4 mm (0.3 ~ 1.0 mm optional)
Filament Compatibility Engineering Plastics: PLA, ABS, ASA, PC, Nylon, PETG, PVDF, Carbon Fiber
High-temperature Materials: UltraPA, UltraPA-GF, UltraPA-CF, PPSU, PEI (ULTEM)
Ultra-performance Materials: PEEK, CF-PEEK (Carbon fiber), GF-PEEK (glass fiber), PEKK, etc.
Speed
Best Printing Speed 55 mm/s
Max. Printing Speed 180 mm/s
Electrical
Input Power 200V ~ 240V, 20A
Rated Power 4600 W
Screen 4.3'' full-color touchscreen, multi-language
Print Method USB Connectivity/USB Disk
Mechanical
Cooling Air pump cooling & water cooling
Platform PCB aluminum + PEEK print board
Positioning Precision X, Y axis: 0.0127 mm
Z axis: 0.00125 mm
Extruder Direct Drive
Machine Construction Fully enclosed hot chamber
Bed Leveling Manually/Automatic
Temperature
Nozzle Max. Temperature 480°C
Chamber Temperature 120°C
Platform Max. Temperature 200°C
Direct Annealing Temperature 0 ~ 400°C
Software
Software Creatware, Simplify3D, Cura, Slic3r
Operating Systems Windows (all), macOS
Print File Type STL, OBJ, AMF, Gcode
Special Functions
Outage Restored Save data when power is off
Filament Detection Pause printing when filament runs out
Direct Annealing System (DAS) Instant controllable annealing process during printing to ensure high-quality, warp-free prints
Heat Insulation Triple heat insulation
Emergency Stop Switch Supported
High-Temperature Accessories High-temperature resistant motors, linear rails, belts, and circuits for long-duration printing at high temperatures
Size & Weight
Machine Size 720 x 700 x 941.5 mm
Net Weight (N.W) 110 kg
Packing Size 820 x 720 x 1080 mm
Gross Weight (G.W)  319.67 lb (145 kg)


CreatBot PEEK-300 Technical Data Sheet

View CreatBot PEEK-300 Technical Data Sheet

View CreatBot High-Temp Capability Manual

CreatBot Preliminary Setup Video

CreatBot Inter-Brand Comparison Chart

View CreatBot Inter-Brand Specs Comparison Chart

Owner's Manual

View CreatBot PEEK-300 User Manual

Standard Warranty

View CreatBot PEEK-300 Standard 1-Year Warranty
