🟢authorized PARTNER

SKU:[S]5.11.19022A01

Raise3D Industrial PA12 CF+ 1.75 mm 1 kg Filament- RFID 5.11.19014A01

Raise3D Industrial PA12 CF+ 1.75 mm 1 kg Filament- RFID 5.11.19014A01

Regular price $169.00 USD
Regular price Sale price $169.00 USD
Sale Sold out

Includes Warranty

30-Day Returns

Unlimited Free Support

Raise3D Industrial PA12 CF+ Filament – RFID Enabled Carbon Fiber Reinforced Nylon for High-Strength Applications

Raise3D Industrial PA12 CF+ Filament is a carbon fiber–reinforced composite based on Polyamide 6,12 (PA6,12)—a hybrid nylon formulation that combines the strength and toughness of PA6 with the low moisture absorption and stability of PA12. With 15 wt% short carbon fibers, this filament offers superior stiffness, strength-to-weight ratio, and dimensional stability, making it one of the most advanced materials in Raise3D’s industrial filament line.

Engineered for functional, lightweight end-use components, PA12 CF+ provides exceptional Z-direction strength, thermal resistance, and surface quality. After annealing, both its mechanical and thermal properties are further enhanced—making it ideal for demanding automotive, aerospace, and manufacturing applications.


Key Benefits

  • Carbon Fiber Reinforcement: 15% carbon fiber content improves rigidity, tensile strength, and surface quality.

  • Hybrid Nylon Composition: Combines PA6’s strength with PA12’s low moisture absorption and dimensional stability.

  • Superior Interlayer Bonding: Enhanced Z-axis strength for durable, load-bearing parts.

  • Lightweight & Strong: High strength-to-weight ratio ideal for industrial-grade applications.

  • Heat & Chemical Resistance: Maintains structure and performance in harsh environments.

  • Improved Post-Annealing Properties: Increased heat deflection and stiffness after thermal treatment.

  • RFID Integration: Automatically detected by Raise3D Pro3 HS Series printers for seamless setup.


Specs

Specification Details
Material Type PA12 CF+ (15% Carbon Fiber Reinforced Nylon 6,12)
Filament Diameter 1.75 mm
Net Weight 1 kg
Color Black (PMS: Black 6U / RAL: 9004)
Fiber Content 15 wt.% Carbon Fiber
Tensile Strength Improved over standard PA12 CF
Strength-to-Weight Ratio High
Z-Direction Strength Enhanced interlayer bonding
Heat Resistance (After Annealing) High thermal stability
Compatible Printers Raise3D E2CF, Raise3D RMF500
Recommended Support Filament Raise3D Industrial PA12 CF Support
RFID Functionality Auto filament detection and print parameter adjustment
Price $169.00 USD

Applications

  • Manufacturing Tools: Durable jigs, fixtures, and production aids.

  • Automotive Components: Lightweight, heat-resistant parts for structural and mechanical systems.

  • Aerospace Applications: High-strength, low-weight parts with precise tolerances.

  • Functional Prototypes: Test-ready components that perform under stress.

  • Industrial Equipment: Reliable for housings, brackets, and replacement components.


Compatibility

  • Printers: Raise3D E2CF and Raise3D RMF500.

  • Support Filament: Raise3D Industrial PA12 CF Support Filament.

  • Slicing Profiles: Available for E2CF (Speed, Standard, High Quality).

  • Nozzle Requirement: Use wear-resistant hardened steel or ruby nozzle.

  • Slicing Software: Latest version of ideaMaker.

  • Storage Recommendation: Use a Raise3D Filament Dry Box to avoid moisture uptake.


Why Choose Raise3D Industrial PA12 CF+ Filament?

Raise3D PA12 CF+ stands out as a high-performance, industrial-grade filament offering a rare combination of lightweight strength, dimensional stability, and durability. Its hybrid PA6,12 base polymer delivers improved interlayer adhesion and reduced warping, while its carbon fiber reinforcement ensures rigidity and precision unmatched by standard composites.

Ideal for engineering, aerospace, and automotive professionals, this filament provides reliable mechanical performance, heat resistance, and smooth printability, even in demanding production environments.


FAQs

What is Raise3D PA12 CF+ Filament?

A carbon fiber–reinforced nylon filament based on PA6,12, offering a combination of strength, low moisture absorption, and high dimensional accuracy.


How is PA12 CF+ different from standard PA12 CF?

PA12 CF+ features a hybrid nylon blend (PA6,12) for improved strength-to-weight ratio, better Z-direction adhesion, and enhanced dimensional stability.


What applications is PA12 CF+ best suited for?

Ideal for automotive, aerospace, and manufacturing applications where lightweight strength and thermal performance are essential.


Which printers support PA12 CF+?

Optimized for Raise3D E2CF and RMF500 printers, both designed for fiber-reinforced composites.


Is PA12 CF+ filament RFID-enabled?

Yes. The RFID tag allows Raise3D Pro3 HS Series printers to automatically detect the filament and load correct print parameters.


Do I need a special nozzle to print PA12 CF+?

Yes. Due to carbon fiber content, use a wear-resistant nozzle (hardened steel or ruby) for consistent performance.


Can the properties be improved post-printing?

Yes. Annealing the parts enhances mechanical strength and heat resistance.
